Wire Wrap

Our Wire Wrap is 2.54mm pitch Dual in Line, Single in Line and PLCC sockets which allow for three wraps and incorporate a straight knurled barrel to alleviate pin rotation during the wrapping process.

Dual Row Wire Wrap I.C. Sockets

The W30600 Series uses a screw machined half hard brass outer pin with a beryllium copper contact. The beryllium copper contact can be Gold or pure Tin.

The Outer pin has 3 plating options; RoHS compliant Tin, Tin/Lead or Gold.

The moulding material is 30%GF PBT rated to UL 94 V-0 and features include a pin incorporating a straight knurled barrel to alleviate pin rotation during the wrapping process.

Single Row Wire Wrap I.C. Sockets

The W36600 Series uses a screw machined half hard brass outer pin with a beryllium copper contact, available in Gold or pure Tin.

The Outer pin has 3 plating options; RoHS compliant Tin, Tin/Lead or Gold.

The moulding material is 30%GF PBT rated to UL 94 V-0 and features include a pin incorporating a straight knurled barrel to alleviate pin rotation during the wrapping process.
